Products detail

Forged Round Bar / Grinding Steel Rod for Rod Mill

Name

Forged Round Bar / Grinding Steel Rod for Rod Mill

ShengYe Grinding Steel Rod is directly from heated high carbon alloyed steel bar followed by straightening and in-line heat treatment, tailed to give uniform hardness, high resistance to both abrasion and impact, and resistance to bending.
没有此类产品
Message
Description

                           Grinding Steel Rods



The grinding steel rod can be ordered with the specific requirements of the customer. Our grinding steel rods are mainly used in metallurgy, mines, cement plants, thermal energy, chemical and other industries.

Hardness: 25HRC to 60HRC
Tolerance: per meter for each Max.2mm grinding rod
Microstructure: bainite + perlite + carbide.
Unit consumption: 40% lower than untreated steel.
Characteristics of wear-resistant steel bar:
1. The raw materials of the wear-resistant grinding steel rods are ordered from the well-known steel mill, the quality of the products that are guaranteed.
2.  The hardness of this new type of wear-resistant grinding steel rod can reach HRC25-35, HRC35-45, HRC45-60, HRC> 60.
3.  Wear-resistant grinding steel rod can be ordered with customer's requirements, the diameter, length and hardness can be produced with customer's requirements, greatly improve the flexibility, but also reduce the production cost.
4.  The wear-resistant grinding steel rod adopts the latest production technology, the wear resistance is increased considerably, it is not easy to mess up, its wear resistance is higher than the common bar on the market 4-6 times .



Grinding Steel Rod Classification and Chemical Composition

Name C Mn Si S P Cr
SY-03-60Mn 0.57-0.65 0.70-1.10 0.17-0.37 0.05max 0.05max 0.25max
SY-04-65Mn 0.62-0.75 0.90-1.20 0.17-0.37 0.05max 0.05max 0.25max
SY-05-B2 0.75-0.85 0.70-0.90 0.17-0.35 0.05max 0.05max 0.40-0.60
SY-06-B3 0.50-0.65 0.40-1.00 1.35-1.85 0.05max 0.05max 0.80-1.20
SY-07-BL 0.55-0.75 0.65-0.85 0.15-0.35 0.05max 0.05max 0.70-1.20
SY-08-BG 0.90-1.05 0.35-0.95 0.15-0.35 0.05max 0.05max 1.0-1.70

Grinding steel rods data



DIA(mm) 30-50 60-70 75-90 100-120 130 hardness
Length 3.0-6.0 3.0-5.82 3.0-6.0 customizable customizable

HRC35-60
HRC>60

We can produce the grinding steel rod according to the length of the customer's mill.





                             Our Factory

SHANGDONG SHENGYE GRINDING BALL CO.,LTD  specializes in the production of grinding steel ball for ball mill. Staff are trained and selected by strict overseas technology . The quality of products is consistent and the specifications are complete. The annual output of diameter DIA 20MM-DIA 150MM grinding steel ball is 100000 tons.
Due to the application of internationally advanced technology and manufacture experience ,our grindingsteel balls have the advantages of rubbing endurance, crashing tolerance and roundness persistence ,compared to other products in this field. We record the data for our products, follow up customers and drop in services at calling to solve customers' uncertainties.



                          Testing Equipment



Our company has a first-class laboratory, and equipped with advanced testing equipment, such as spectrometer, hardness tester, microscope, drop tester, impact tester, laser cutting machine, etc.,to ensure that our products from raw material into the factory to the prduction process to the shipment of every link quality control assurance and traceability.





                        Packing and Delivery


1. Ocean shipping
2. Customers designated transportation mode.
3. Packing Details  :Packing in bundles, 9-20 pcs per bundle.
4. Delivery Details : Witnin 15-20 days after received the payment or LC at sight.



                                    Our Service


1. If any quality problems, we are committed to a full refund.
2. Pay a return visit once a week.
3. When a fault occurs we will deal with it for the first time and resolve problem within 1-2 working days.
4. If you have any question, please contact me freely. We will give you a reply in the first time.



                         Certificate Show


Our
forged steel balls have passed the TUV ISO9001,  ISO14001, OHSAS 18001, SGS, BV ect. Certificates.

Any question about the forged steel balls, pls feel free to contact us as below:

Ina / MANAGER

SHANDONG SHENGYE GRINDING BALL CO.,LTD
 E-mail: sinaixzl004@163.com
TEL:+86-15634131183
